LVCD16 D-2LS
Linear ball bearing units are designed for use on shafts and consist of linear ball bearing and housing.
Alternativ Article No.: 10172060,LVCD16D2LS,EWXLVCD16,LVCD16EWX
TECHNICAL DATA
Inner dimension: 16 mm
Outer dimension: 26 mm
Width: 36 mm
Weight: 0,178 kg
EAN: 7333314231130
Material: Standard bearing steel
Seal: Sealed on all sides
Temperature range: -30 to +80 °C
Version: Closed version
Angle compensation: Self-alignment up to 30'
Operating clearance: Non-adjustable
Series: 16 series
