LTBR12 -2LS
Linear ball bearing units are designed for use on shafts and consist of linear ball bearing and housing.
Alternativ Article No.: 10134780,LTBR122LS,EWXLTBR12,LTBR12EWX
TECHNICAL DATA
Inner dimension: 60 mm
Outer dimension: 40 mm
Width: 33 mm
Weight: 0,171 kg
EAN: 7316570012514
Seal: Sealed on all sides
Temperature range: -30 to +80 °C
Version: Closed version
Angle compensation: Without misalignment compensation
Operating clearance: Non-adjustable
Material: Standard bearing steel
Series: 12 series
