LME25
Linear ball bearings have a compact design and enable jerk-free longitudinal movement along the shaft.
Alternativ Article No.: 10191784,THKLME25,LME25THK
TECHNICAL DATA
Inner dimension: 25 mm
Outer dimension: 40 mm
Width: 58 mm
Weight: 0,215 kg
Material: Standard bearing steel
Seal: None, open bearing
Temperature range: -30 to +80 °C
Version: Closed version
Angle compensation: Without misalignment compensation
Series: 25 series
