LME20 UU
Linear ball bearings have a compact design and enable jerk-free longitudinal movement along the shaft.
Alternativ Article No.: 10191821,LME20UU,THKLME20,LME20THK
TECHNICAL DATA
Inner dimension: 20 mm
Outer dimension: 32 mm
Width: 45 mm
Weight: 0,095 kg
Material: Standard bearing steel
Seal: Sealed on all sides
Temperature range: -30 to +80 °C
Version: Closed version
Angle compensation: Without misalignment compensation
Series: 20 series
