LM8
Linear ball bearings have a compact design and enable jerk-free longitudinal movement along the shaft.
Alternativ Article No.: 10191664,THKLM8,LM8THK
TECHNICAL DATA
Inner dimension: 8 mm
Outer dimension: 15 mm
Width: 24 mm
Weight: 0,016 kg
Material: Standard bearing steel
Seal: None, open bearing
Temperature range: -30 to +80 °C
Version: Closed version
Angle compensation: Without misalignment compensation
Series: 8 series
