LBCR30 D-LS/HV6
Linear ball bearings have a compact design and enable jerk-free longitudinal movement along the shaft.
Alternativ Article No.: 10171924,LBCR30DLSHV6,EWXLBCR30,LBCR30EWX
TECHNICAL DATA
Inner dimension: 30 mm
Outer dimension: 47 mm
Width: 68 mm
Weight: 0,166 kg
EAN: 7316576866258
Seal: Contact seal on one side
Material: Stainless steel
Series: 30 series
Temperature range: -30 to +80 °C
Version: Closed version
Angle compensation: Without misalignment compensation
