LBCR25 D-2LS/HV6
Linear ball bearings have a compact design and enable jerk-free longitudinal movement along the shaft.
Alternativ Article No.: 10171916,LBCR25D2LSHV6,EWXLBCR25,LBCR25EWX
TECHNICAL DATA
Inner dimension: 25 mm
Outer dimension: 40 mm
Width: 58 mm
Weight: 0,123 kg
Seal: Sealed on all sides
Material: Stainless steel
Series: 25 series
Temperature range: -30 to +80 °C
Version: Closed version
Angle compensation: Without misalignment compensation
