LBCD16 D
Linear ball bearings have a compact design and enable jerk-free longitudinal movement along the shaft.
Alternativ Article No.: 10171871,LBCD16D,EWXLBCD16,LBCD16EWX
TECHNICAL DATA
Inner dimension: 16 mm
Outer dimension: 26 mm
Width: 36 mm
Weight: 0,025 kg
Material: Standard bearing steel
Series: 16 series
Seal: None, open bearing
Temperature range: -30 to +80 °C
Version: Closed version
Angle compensation: Self-alignment up to 30'
