KWVE25 -B-RROC-V1-G3
Guide carriages are used when a high load capacity, running and positioning accuracy is required.
Alternativ Article No.: 10160484,KWVE25BRROCV1G3,INAKWVE25,KWVE25INA,SCHAEFFLERKWVE25,KWVE25SCHAEFFLER
TECHNICAL DATA
Weight: 0,708 kg
EAN: 4054362987130
Lubrication & Maintenance: Relubricatable
Seal: End seals and sealing strips
Material: Steel with Corrotect rust protection, plastic
Tolerance class: INA G3
Preload: Light preload
Design: Flange carriage
Temperature range: -10 to +100 °C
Type of rolling elements: Balls
Ball-/Roller rows: Four-row
Ball chain: Without ball chain
Series: 25 series
Version: Standard version
