HDR20 LCSS
Guide carriages are used when a high load capacity, running and positioning accuracy is required.
Alternativ Article No.: 10192139,HDR20LCSS,THKHDR20,HDR20THK
TECHNICAL DATA
Weight: 0,565 kg
Version: Wide and long design
Tolerance class: THK normal class
Seal: End seals, sealing strips and inner seals
Ball chain: Without ball chain
Lubrication & Maintenance: Can be relubricated (via the lubrication nipple)
Series: 20 series
Preload: Normal preload
Material: Steel, plastic
Temperature range: -20 to +80 °C
Design: Flange carriage
Type of rolling elements: Balls
Ball-/Roller rows: Four-row
