HDR15 VSS
Guide carriages are used when a high load capacity, running and positioning accuracy is required.
Alternativ Article No.: 10192115,HDR15VSS,THKHDR15,HDR15THK
TECHNICAL DATA
Weight: 0,18 kg
Tolerance class: THK normal class
Seal: End seals, sealing strips and inner seals
Preload: Normal preload
Ball chain: Without ball chain
Lubrication & Maintenance: Can be relubricated (via the lubrication nipple)
Material: Steel, plastic
Temperature range: -20 to +80 °C
Design: Block carriage
Type of rolling elements: Balls
Ball-/Roller rows: Four-row
Version: Low design
Series: 15 series
