3001 -B-2Z
Angular contact ball bearings support radial-axial combined loads. As the nominal contact angle increases, the axial load carrying capacity increases. Therefore, angular contact ball bearings are better for supporting higher axial loads than deep groove ball bearings.
Alternativ Article No.: 10127258,3001B2Z,ZEN3001,3001ZEN,3001BZZ
TECHNICAL DATA
Inner dimension: 12 mm
Outer dimension: 28 mm
Width: 12 mm
Weight: 0,02 kg
Contact angle: 25 degree
Cage: Polyamide cage
Seal: Cover on both sides
Clearance: Normal radial clearance
Temperature range: -20 to +120 °C
Arrangement: Standard version
Outer ring: Without flange/groove
Tolerance class: Tolerance class P0/PN2 / ABEC 1
Ball rows: Double row bearing
Material: Standard bearing steel
