3000 -B-2RS
Angular contact ball bearings support radial-axial combined loads. As the nominal contact angle increases, the axial load carrying capacity increases. Therefore, angular contact ball bearings are better for supporting higher axial loads than deep groove ball bearings.
Alternativ Article No.: 10127256,3000B2RS,ZEN3000,3000ZEN
TECHNICAL DATA
Inner dimension: 10 mm
Outer dimension: 26 mm
Width: 12 mm
Weight: 0,015 kg
Cage: Polyamide cage
Clearance: Normal radial clearance
Temperature range: -20 to +120 °C
Tolerance class: Tolerance class P0/PN2 / ABEC 1
Arrangement: Standard version
Contact angle: 40 degree
Seal: Lip seal on both sides
Outer ring: Without flange/groove
Ball rows: Double row bearing
Material: Standard bearing steel
