FAG - Barrel roller bearings 20230 MB
Spherical roller bearings are adjustable-angle single-row roller bearings. They are used when high radial forces occur impulsively and misalignments have to be compensated. The axial load carrying capacity is low.
Alternativ Article No.: 10007389,20230MB,FAG20230,20230FAG
TECHNICAL DATA
Inner dimension: 150 mm
Outer dimension: 270 mm
Width: 45 mm
Weight: 11,6 kg
EAN: 4012801185837
Seal: None, open bearing
Clearance: Normal radial clearance
Cage: Brass cage
Running accuracy: Tolerance class P0/PN2 / ABEC 1
Bore: Cylindrical bore
Temperature range: -30 to +200 °C
